Specifications:
|
Product Type |
1300Mbps USB3.0 WiFi Adapter |
|
Model |
WB801 |
|
Chipset |
RTL8812BU |
|
Color |
Black |
|
bluetooth | |
|
bluetooth Version |
BT V5.0 |
|
Interface |
USB 3.0 |
|
Antenna Type |
5dBi Antenna |
|
RF Power |
18dBm (Max) |
|
Transmission Distance |
10m |
|
Transmit Speed |
3M/s |
|
Working Current |
100mA-200mA (BT WIFI) |
|
Operating System |
Windows 7/8/10 |
|
WIFI | |
|
Antenna Type |
5dBi Antenna |
|
RF Power |
16dBm (Max) |
|
Transmission Distance |
100m (indoor max), 200m (outdoor max) |
|
Wireless Standard |
IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, CSMA/CA with ACK |
|
Frequency |
2.4~2.4835GHz/5.15~5.825GHz |
|
Signal Rate: |
2.4G: 400Mbps 5.8G: 867Mbps |
|
Modulation Mode |
802.11g/n: OFDM 802.11b: CCK(11, 5.5Mbps), QPSK(2Mbps), BPSK(1Mbps) AC80-MCS9: -55 /-1dBm |
|
Wireless Transmission Rate |
802.11ac: Max 867Mbps 802.11b: 11, 5.5, 2, 1Mbps 802.11g: 54, 48, 36, 24, 18, 12, 9, 6Mbps 802.11n: up to 400Mbps |
|
Reception Sensitivity |
802.11b: -76 /-1dBm 802.11g: -65 /-1dBm 802.11n (HT20): -70 /-1dBm 802.11n (HT40): -65 /-1dBm AC80-MCS9: -55 /-1dBm |
|
Transmit Power |
802.11b (CCK) 11Mbps: 18 /-1dBm 802.11g (OFDM) 54Mbps: 15 /-1dBm 802.11n (OFDM) 54Mbps: 15 /-1dBm 802.11ac (AC80) MCS9: 12 /-2dBm |
| Spread-Spectrum Technique |
DSSS |
| Wireless Security |
WPA/WPA2/802.11x/802.11i |
| Working Current |
100mA-200mA (BT WIFI) |
